Hey All

Our Aluminum framing is sold exclusively through Bosch Rexroth-authorized distributors, our network of full-service stocking dealers across North America. Every distributor stocks a complete inventory of all common components and employs Aluminum framing product experts to help with design, engineering and applications. T-Slot Blocks Mount these versatile blocks to any flat surface for machine table-style T-slot clamping. They can also be used on a machine table to clamp parts at specific angles or add more total clamping points.

T slot aluminum table saw fenceDeskI was a founder as I wanted to support the game but stopped playing after a few hours as I wanted to let the game mature and flesh out a bit before dedicating too much time and getting frustrated as I knew I would. Now the game seems to be well on track and there seems to be a lot more to do though still very much a work in progress I thought I might stick my oar back in the water.
I wanted to start as I mean to continue so bought an X55 for £119 and an X56 for my son who wants to play for £116, both great deals thankfully as I am always short on cash as I imagine many of us are. I also want a nice hotas mount for my desk and as I have 3D printer I thought I might be able to print some but it just flexes too much no matter what design I try within reason, I dont want something 50mm thick.
Then while using my 3D Printer I thought about how my printer is made with aluminum extrusion, it's fairly cheap and goes together easy so I started designing some mounts. In the process of the design, I did some web searches to see what other might have done and came across the Monstertech Mounts which were for the most part exactly like mine with a few minor exceptions. I was using a cheap chinese push pull clamp for the clamp and I wasn't using a mounting plate for the hotas but instead was using extrusion in place of the mounting plate. Their design looked nicer with the base plate so I decided to replicate it and I liked the Bessey push pull clamp so incorporated that also though it is a large chunck of change.
I could just buy their Mounts and I would if I could afford to, but I need 4 of them for me and my son which works out to over £400 so it's sweat equity over a fat wallet I am afraid.
It works out to less than £48 each so less than half the price. I also used this as a learning tool and designed base plates for several other Hotas models which I can post DXF files for if anyone is interested in having them laser cut or cutting them themselves. I have them for the Warthog Joy Stick and Throttle, the X 55/56 Joystick and Throttle, The x52 Joystick and Throttle, the T1600M FCS Joystick and TWCS Throttle and the CH Products Joystick and Throttle. I could also do any others if supplied with the mounting hole and L x W dimensions of the base.
The price list for 4 mounts works out to
PartSupplierCostQTYTotal CostShipping
40x80L Extrusion 250mm http://www.aluminium-profile.co.uk/acatalog/40x80L-Aluminium-Profile-KJN993130.html£4.724£18.88
40x80L Extrusion 100mm http://www.aluminium-profile.co.uk/acatalog/40x80L-Aluminium-Profile-KJN993130.html£2.344£9.36
D17 Bolt Connectorhttp://www.aluminium-profile.co.uk/cgi-bin/sh001001.cgi?WD=bolt%20d17%20connector&PN=D17-Bolt-Connector-3842535619%2ehtml#SID=12£2.478£19.76
40x80L End Caphttp://www.aluminium-profile.co.uk£1.318£10.48
M5 T Nut (10pk)http://www.aluminium-profile.co.uk£3.002£6.0012.49
M5 X 16MM Socket Countersunk Screws 50 Packhttp://www.screwfix.com/p/socket-countersunk-screws-a2-stainless-steel-m5-x-16mm-50-pack/65156£1.891£1.89collection
Aluminium Plate: 5083 'O' - 4.0 mm - 278mmx 184mmhttp://www.aluminiumwarehouse.co.uk£3.704£14.80
Aluminium Plate: 5083 'O' - 4.0 mm - 278mmx 184mmhttp://www.aluminiumwarehouse.co.uk£3.704£14.80
Aluminium Plate: 5083 'O' - 4.0 mm - 100mm x 160m2http://www.aluminiumwarehouse.co.uk£1.202£2.4012.49
Bessey Push/Pull Toggle Clamp - STC-IHH/25http://www.mytoolshed.co.uk/p1090345/Bessey_STC_Self-Adjusting_Push_Pull_Toggle_Clamp_16mm/product_info.html?utm_source=googleversafeed&vfsku=1090345&gpla=pla&gclid=Cj0KEQjwuZvIBRD-8Z6B2M2Sy68BEiQAtjYS3Nz8KuE_5e12HU7M_IGdAvfwJ7NLMpxLOUOEERhkJk8aAhb98P8HAQ£18.674£74.68Free
Sub Total£158.25
Shipping24.98
Total24.98£189.90£47.48 Each
